LITTELFUSE® bistable automatic smart latching relay
€274,50
incl. VAT 25.5%
The LITTELFUSE® bistable automatic smart latching relay is a 12V DC solid-state relay rated for 300 A continuous current with IP67/IP69K ingress protection. It automatically connects and disconnects battery banks based on alternator or battery charger activity.
Select model3 options
LITTELFUSE bistable automatic relay 12V
€274,50
LITTELFUSE bistable automatic relay 24V
€244,50
Deutsch 6-pole DTM connector
€21,90
In stock
90 % of orders ship within 3 business days
Does this fit your boat?
Sign in and add your boat and we will show compatibility automatically. My boat →
Free shipping on orders over €100 · Free returns within 14 days
Specifications
V12
Control current40 mA*/6 A**
Relay contact position - closes (30 sec) with voltage13.5 V
Relay contact position - closes (90 sec) with voltage13.1 V
Relay contact position - opens (10 sec) with voltage12.3 V
Relay contact position - opens (30 sec) with voltage12.7 V
Relay contact position - opens circuit16.5 V***
Voltage Rating8 80051 – 12V DC
Max Continuous Current300A (1x 4/0 input/output cable)
Inrush Current Rating1500A (1x 4/0 input/output cable)
Ingress ProtectionIP67/IP69K
Operating Temp-40°C to + 85°C
Supports highamp intermittent or continuous current loads
Datasheet Replaces Hotfeed Number D652
Rev101817
Temperature Range50°C to + 105°C
Type Sustained SPDT OnOff-On
Country of originMexico
