Battery switch with remote electric control
€212,95
incl. VAT 25.5%
The Osculati battery switch with remote electric control is a motorized isolator rated at 275 A continuous and 1250 A cranking, operable both remotely via an ON-OFF switch and manually at the unit, with LED status indication. Mounting close to the battery reduces the length and cross-section of main cable required between the battery and helm.
In stock
94 % of orders ship within 4 business days
Does this fit your boat?
Sign in and add your boat and we will show compatibility automatically. My boat →
Free shipping on orders over 100€ · Free returns within 14 days
Specifications
V12/24
Max capacity A - intermittent455
Max capacity A - in continuous275
misure mm67x67x95h
OPTIONAL switch[14.386.09]
Voltage9.5 V DC - 32 V DC
Continuous Current275 A
Intermittent Current455 A
Cranking Current1,250 A
OperationManual On/Off
Motorized OperationOn/Off
Power Draw Switch Off12 mA
Power Draw Switch On15 mA
Switch Operating Current120 nA for 3 seconds at 12V nominal
Dimensions Front67 × 67 × 54 mm
Dimensions Back68 × 68 mm
Compass Diameter51.5 mm
Height31 mm
Base Depth39 mm
Base Width29.3 mm
Wire ColorsBlack (to earth), Red (to LED), Green (to Switch)
Country of originTaiwan
